【Free 12V 12Ah】36V 200Ah LiFePO4 Battery

【Free 12V 12Ah】36V 200Ah LiFePO4 Battery

Regular price $1,675.77 CAD
Regular price $2,399.97 CAD Sale price $1,675.77 CAD
Sale Sold out
Shipping calculated at checkout.
  • New Customer Price: $535.80/PACK
  • Compact: 19.0 x 6.6x 9.4 Inches | 45.20 lbs
  • Safe: Low-temperature cut-off protection
  • Premium: EV grade A+ LiFePO4 cells
  • Durable: 5,000-15,000 deep discharge cycles
  • Reliable: Built-in 200A BMS | 2560W | 2560Wh
  • Scalable: Expandable max 4S4P, up to 40.96kWh
  • Waterproof: IP65
  • Certification: MSDS/UN38.3/FCC/CE/ROHS/UL

Low stock: 10 left

Description

View full details

SAVE Thousands - Build your own solar energy storage! deep cycle battery @inventor KR | 299K+ Views

WattCycle Deep Cycle Battery: Grade A+ Power

  • Brand New EV Grade A+ Cells
  • Superior Quality and Reliability
  • Longer Lifespan
  • High Energy Density
  • Safety and Stability
  • Consistent Performance
  • High Performance in Extreme Conditions
  • Environmental Friendliness

WattCycle Lithium Battery Safety: Premium BMS Protection

  • Max. Cont. Discharge Current: 200A
  • Max. Cont. Charge Current: 200A
  • Max. Discharge Current (5s):300±50A
1 of 2

Connect in Series or Parallel

You can wire lifepo4 battery 12V 200AH Core Series Batteries in series to build a 24V, 36V, or even 48V system in your RV.

1 of 2

LiFePO4 Lithium Battery One-Stop Solution

1 of 2
  • 14.6V 20A Charger

    1) 3 Charging Phase: I1, I2, I3
    2) Recommended Charging Rate: 0.1C~5C
    3) Full Charging: 10 hours (0.1C)

  • Solar Energy Plate

    1) Recommended Charging Current: 0.1C~0.5C
    2) Recommended Charging Voltage: 14.4~14.6V

  • Power Generator

    1) Charging: DC to DC
    2) Recommended Charger: 20A DC-DC Charger
    3)Full Charging: 5 hours

1 of 3

Tech Specs



GENERAL

Dimensions (Inches) 19.0 (L) x 6.6 (W) x 9.4 (H)
Weight 45.20lbs / 20.5kg
Waterproof Rating IP65
Warranty 7 years
Housing Material ABS (Flame Retardant Plastic)
Terminal M8 bolts

BATTERY

Cell EV Grade A+ LiFePO4 Cells
Nominal Voltage 12.8V
Nominal/Usable Capability 200Ah
Energy 2560Wh
Cycle Life 5,000 cycles @100% DOD, 6,000 cycles @80% DOD, 15,000 cycles @40% DOD
Max Depth of Discharge (DOD) 100%
Max. Expansion 4S4P
Certifications SDS/UN38.3/FCC/CE/ROHS/UL
Internal Resistance ≤40mΩ

BMS

BMS 200A
Max. Continuous Output Power 2560W
Max. Continuous Charge Current 200A
Max. Continuous Discharge Current 200A
Max. Discharge Current  300±50A (≤5s)

CHARGE

Charge Voltage 14.6V ± 0.2V
Charge Method CC/CV
Recommend Charge Current 40A (0.2C)
Charge Temperature 0℃ to 50℃ / 32℉ to 131℉
Discharge Temperature: -20℃ to 55℃ / -4℉ to 131℉
Storage Temperature 0℃ to 55℃ / 32℉ to 131℉
Low-Temperature Protection Yes (32℉/0℃)
Low-Temperature Charging Protection Auto Recovery Yes (41℉/5℃)
