Smaller, More Portable in Daily Use
Unlocking Essential Advantages
Top-Tier Safety with BMS
Power up with the Reliable Battery
Efficient Gardening with WattCycle
Power Your Life with Versatile Lithium Solutions
Tech Specs
GENERAL
Dimensions (Inches) | 5.94 (L) x 2.55 (W) x3.77(H) |
Weight | 2.22lbs / 1kg |
Waterproof Rating | IP65 |
Warranty | 5 years |
Housing Material | ABS (Flame Retardant Plastic) |
Terminal | F2 bolts |
BATTERY
Cell | EV Grade A+ LiFePO4 Cells |
Nominal Voltage | 12.8V |
Nominal/Usable Capability | 8Ah |
Energy | 102.4Wh |
Cycle Life | 5,000 cycles @100% DOD, 6,000 cycles @60% DOD, 15,000 cycles @40% DOD |
Max Depth of Discharge (DOD) | 100% |
Max. Expansion | 4S4P |
Certifications | SDS/UN38.3/FCC/CE/ROHS/UL |
Internal Resistance | ≤40mΩ |
BMS
BMS | 8A |
Max. Continuous Output Power | 102.4W |
Max. Continuous Charge Current | 8A |
Max. Continuous Discharge Current | 8A |
CHARGE
Charge Voltage | 14.6V ± 0.2V |
Charge Method | CC/CV |
Recommend Charge Current | 10A (0.2C) |
Charge Temperature | 0β to 50β / 32β to 131β |
Discharge TemperatureοΌ | -20β to 55β / -4β to 131β |
Storage Temperature | 0β to 55β / 32β to 131β |
Low-Temperature Protection | Yes (32β/0β) |
Low-Temperature Charging Protection Auto Recovery | Yes (41β/5β) |
